    Frequency Inverter 22kw Three Phase 380v 400v 480v Variadores 30HP

    Ask Lasest Price
    Brand Name : ZONCN
    Model Number : NZ200T-22GY-4
    Certification : CE
    Payment Terms : T/T,L/C,Paypal
    Supply Ability : 100,000 pcs/month
    Delivery Time : 7-30 days
    • Product Details
    • Company Profile

    Frequency Inverter 22kw Three Phase 380v 400v 480v Variadores 30HP

    Frequency Inverter 22kw Three Phase 380v 400v 480v Variadores 30HP


    NZ200 Series Economical Vector Inverter Features:

    Control Methods: Supports both open-loop vector control and V/F control.
    Overload Capability: Can sustain 150% of the rated current for up to 60 seconds and 180% for 3 seconds.
    Exceptional Performance: Demonstrates outstanding adaptability to diverse environmental conditions.
    Space-Saving Design: Features a straightforward and compact structure for hassle-free installation.
    Robust Torque Performance: Guarantees seamless motor startup even under heavy load conditions.
    Innovative Functions: Incorporates momentary power loss ride-through and rapid current limiting, minimizing fault alarm occurrences.
    Extensive Safety Features: Includes protections against output phase loss, overcurrent, overvoltage, overload, overheating, and more.
    PMSM Compatibility: Designed to support permanent magnet synchronous motor control (Z200T series).
    Power Capacity: Available in a wide range from 0.4 kW to 630 kW.


    NZ200 Series VFD Features
    Series
    Economical
    Communication
    RS485
    Input voltage
    220v/380v/ 440v/480v
    Protection function
    over-current/over-voltage/overload/over-heat/output phase loss protection, etc
    Power range
    0.4kw-630kw
    PM motor
    Support
    Control mode
    Vector control
    Certificate
    CE
    Inverter size
    Compact
    Warranty
    18 months
    24V terminal
    Have
    OEM
    Support


    Specification

    Model
    Input Voltage (V)
    Rated output power ( KW)
    Rated input current(A)
    Rated output current (A)
    Motor power ( KW)
    NZ200-0R4G-2


    1PH 220V±15%
    0.4
    5.4
    2.5
    0.4
    NZ200-0R75G-2
    0.75
    7.2
    5
    0.75
    NZ200-1R5G-2
    1.5
    10
    7
    1.5
    NZ200-2R2G-2
    2.2
    16
    11
    2.2
    NZ200-3R7G-2
    3.7
    17
    16.5
    3.7
    NZ200-0R4G-4













    3PH 380V±15%
    0.4
    3.4
    1.2
    0.4
    NZ200-0R75G-4
    0.75
    3.8
    2.5
    0.75
    NZ200-1R5G-4
    1.5
    5
    3.7
    1.5
    NZ200-2R2G-4
    2.2
    5.8
    5
    2.2
    NZ200-3R7G/5R5P-4
    3.7
    10.7
    9
    3.7
    NZ200-5R5G/75R5P-4
    5.5
    14.6
    13
    5.5
    NZ200-7R5G/11P-4
    7.5
    20
    17
    7.5
    NZ200-11G/15P-4
    11
    26
    25
    11
    NZ200-15G/18.5P-4
    15
    35
    32
    15
    NZ200-18.5G/22P-4
    18.5
    38
    37
    18.5
    NZ200-22G/30P-4
    22
    46
    45
    22
    NZ200-30G/37P-4
    30
    62
    60
    30
    NZ200-37G/45P-4
    37
    76
    75
    37
    NZ200-45G/55P-4
    45
    90
    90
    45
    NZ200-55G-4
    55
    105
    110
    55
    NZ200-75G/90P-4
    75
    140
    150
    75
    NZ200-90G/110P-4
    90
    160
    176
    90
    NZ200-110G/132P-4
    110
    210
    210
    110
    NZ200-132G/160P-4
    132
    240
    253
    132
    ...
    ...
    ...
    ...
    ...
    NZ200-450G/500P-4
    450
    790
    790
    450


    ZONCN NZ200 Applications
